ORCA Modtreme 4 M4 6.5T Sensored Brushless Modified Motor – MO26MTM465T

The ORCA Modtreme 4 M4 6.5T Sensored Brushless Motor is a next-generation competition motor developed for racers demanding outstanding speed, efficiency and precise power delivery.

Designed for modified-class 1/10 scale touring cars and off-road racing vehicles, the Modtreme 4 combines a hand-wound stator with an optimised 12.1mm rotor. Its sensored design provides smooth startup, accurate throttle response and predictable power delivery throughout the RPM range.

The redesigned motor housing improves cooling while reducing overall weight by approximately 3% compared with the previous generation. ORCA has also moved the solder terminals inward, positioning more of the motor’s mass towards the vehicle’s centreline. This improves chassis balance and helps the vehicle transition more quickly through rapid left-to-right direction changes.

Factory-installed titanium motor screws reduce weight at the highest point of the motor while providing excellent strength and durability. Its standard 540-size dimensions allow installation in a wide range of competition RC chassis.

The 6.5-turn winding offers a strong balance of acceleration, top speed and controllability, making it suitable for modified racing applications where manageable power delivery is just as important as outright performance.

Key Features

• High-performance 6.5T modified winding
• Sensored brushless operation
• Hand-wound competition stator
• Standard 540-size configuration
• Optimised 12.1mm rotor
• Smooth and precise throttle response
• Strong acceleration and high RPM performance
• Approximately 3% lighter than the previous generation
• Redesigned housing for improved cooling
• Inward-positioned solder terminals
• More centralised motor mass
• Improved chassis balance and direction changes
• Factory-installed titanium motor screws
• Suitable for competition on-road and off-road racing

Specifications

• Brand: ORCA
• Series: Modtreme 4 M4
• Part number: MO26MTM465T
• Motor type: Sensored brushless
• Motor class: Modified competition
• Turns: 6.5T
• Motor size: Standard 540
• Stator: Hand wound
• Rotor diameter: 12.1mm
• Standard rotor: RT26M412133
• Motor screws: Titanium
• Application: 1/10 scale competition RC vehicles

Suitable Applications

• 1/10 modified touring cars
• 1/10 competition pan cars
• 1/10 2WD racing buggies
• 1/10 4WD racing buggies
• Carpet racing
• Asphalt racing
• Competition off-road racing

Package Contents

• 1 × ORCA Modtreme 4 M4 6.5T Sensored Brushless Motor

Required to Complete

• Sensored brushless ESC rated for a 6.5T motor
• Suitable competition battery
• Compatible sensor cable
• Motor wires and connectors
• Suitable pinion gear

Correct gearing will depend on the vehicle, track and operating conditions. Always monitor motor and ESC temperatures during initial setup.
